• Paint, solid
• Bumper, front, chrome (Includes body-color lower with SLE or SLT Models.)
• Bumper, rear, chrome step, includes pad (Not available with (ZW9) Pickup bed, delete.)
• Air dam, Gray
• Wheel flares, front only (With (C4M) GVWR, 9,900 lbs. includes rear wheel flares. - See Color & Trim section for available colors)
• Grille, chrome surround
• Headlamps, dual halogen composite, includes flash-to-pass feature and automatic lamp control
• Daytime running lamps, includes automatic exterior lamp control
• Fog lamps, front, halogen (Not available with (ZW9) Pickup bed, delete)
• Lamps, amber roof marker (Standard on (C7W) GVWR, 11,400 lbs. only)
• Lamps, dual cargo area lamps
• Mirrors, outside rearview, manual folding, power, heated, Black (May be substituted with (DPF) Mirrors, outside rearview, power, heated, camper-style or upgradeable to (DL3) Mirrors, outside rearview, power folding, power, heated when (C4M) GVWR, 9,900 lbs. is ordered)
• Glass, Solar-Ray deep tinted (all windows except light tinted glass on windshield, driver and front passenger) (With Regular Cab Models, includes rear window. - With Extended and Crew Cab Models, includes rear and rear quarter windows. - With (C49) Defogger, rear-window, electric, includes light-tinted rear window.)
• Wipers, intermittent, front wet-arm with pulse washers
• Tailgate protection, top of tailgate protection cap (Not available with (ZW9) Pickup bed, delete.)

• Seat trim, Leather (Not available with Regular Cab Models. - Extended Cab Models include Front Leather seating surfaces with Rear Vinyl Bench. - Crew Cab Models include Front and Rear Leather Appointed seating surfaces)
• Seats, front power reclining full-feature buckets, includes adjustable head restraints, floor console, driver and passenger power lumbar, driver and front passenger 10-way power adjustable, dual inboard armrests, heated driver and passenger cushion and back, 2-position driver-side memory and storage pockets
• Seats, rear bench, folding, 3-passenger (includes top tethers and lower anchors for child seat)
• Seat adjuster, power, driver 6-way (With (AN3) Seats, front power reclining full-feature buckets, includes 10-way adjuster)
• Seat adjuster, power, front passenger 10-way (Included and only available with (AN3) Seats, front power reclining full-feature buckets.)
• Console, floor, includes storage compartment and dual cupholders
• Floor covering, color-keyed carpeting, and rubberized vinyl floormats (with Extended Cab, includes rear floormats)
• Steering wheel, leather-wrapped rim, Black, steel sleeve, includes theft-deterrent locking feature
• Theft-deterrent system, PASSLock II
• Warning tones, headlamp on, key-in-ignition, driver and passenger seat belt reminders, turn signal on
• Defogger, rear-window, electric (Deleted when (A28) Window, rear sliding is ordered)
• Cruise control, electronic with set and resume speed, includes telltale in instrument panel cluster
• Door locks, power
• Windows, power, includes driver express-down
• Keyless entry, remote, includes 2 transmitters, panic button and content theft alarm
• OnStar, 1-year Safe and Sound Service, includes automatic notification of air bag deployment, emergency services, roadside assistance, stolen-vehicle tracking, AccidentAssist, remote door unlock, remote diagnostics, online concierge and remote horn and lights. Drivers can also opt for other available OnStar services, including making and receiving voice-activated, hands-free phone calls with Personal Calling and getting location-based traffic and weather reports with Virtual Advisor.
• Air conditioning, dual-zone, automatic, individual climate settings for driver and right front passenger (Must be substituted with (CJ3) Air Air conditioning, dual-zone, manual when (VYU) Snow Plow Prep Package is ordered. - Not available with (VYU) Snow Plow Prep Package.)
• Sound system, ETR AM/FM stereo with 6-disc CD changer, includes seek-and-scan, digital clock, auto-tone control, speed-compensated volume, TheftLock, Radio Data System (RDS), and Bose speaker system (includes 6-speakers, Bose amplifier and Bose Subwoofer) (May be substituted with (UB1) Sound system, AM/FM stereo with CD and cassette player.)
• Sound system feature, steering wheel mounted radio controls, Radio and Information Center (DIC). Provides access to enhanced Driver Information Center features and information.
• Sound system feature, rear audio controls, includes dual headphone jacks (headphones not included), power outlet and controls for volume, station selection and media (Requires Crew Cab Models.)
• Cupholders, front (Also includes rear cupholders on Extended and Crew Cab Models)
• Cigarette lighter, on instrument panel
• Power outlets, auxiliary, covered, 2 dash-mounted, 12-volt
• Headliner, Shale-colored cloth, with matching retainer moldings
• Mirror, inside rearview, electrochromic (light-sensitive auto dimming) 8-point compass and outside temperature indicator
• Visors, padded, Shale-colored, driver and passenger side with cloth trim, extenders, pocket on driver side and vanity mirror on passenger side
• Console, overhead mini, includes map lights
• Assist handle, front passenger (Also includes rear outboard passenger assist handle on Extended and Crew Cab Models.)
• Lighting, dome lamp, reading, courtesy, illuminated entry feature, backlit instrument panel switches and door handle-activated illuminated entry
• Door trim, side reflectors (Also includes lights on SLE and SLT Models.)
• Coat hook, driver side (Also includes passenger side coat hook on Extended and Crew Cab Models.)

• Brakes, 4-wheel antilock, 4-wheel disc
• Air bags, frontal, driver and right front passenger (Regular and Extended Cab Models includes passenger side deactivation switch. - Always use safety belts and proper child restraints, even with air bags. Children are safer when properly secured in a rear seat. See the Owner's Manual for more safety information.)
• Daytime running lamps, includes automatic exterior lamp control

Additional Packages

• Differential
• Locking
• Heavy-Duty
• Rear
• Engine
• Duramax 6600 Turbo Diesel V8 (With Manual Transmissions 300 Hp [223.8 Kw] @ 3000 Rpm
• 520 Lb.-Ft. [702.0 N-M] @ 1600 Rpm) (With Automatic Transmissions 310 Hp [231.2 Kw] @ 3000 Rpm
• 590 Lb.-Ft. [796.5 N-M] @ 1600 Rpm) (Includes (Tq3) Battery
• Heavy-Duty Dual
• 770 Cold-Cranking Amps
• (K47) Air Cleaner
• High Capacity
• (K05) Engine Block Heater)
• Paint
• Solid (Std)
• Rear Axle
• 3.73 Ratio

• SOUND SYSTEM FEATURE XM SATELLITE RADIO is 100 channels of digital quality sound that goes wherever you go-coast to coast. Displays song title artist and entertainment genre
• PAINT SOLID (STD)
• TRAILERING WIRING PROVISIONS FOR CAMPER 5TH WHEEL AND GOOSENECK TRAILER includes additional 8-way wiring harness routed to front of pickup box and added 7-way sealed connector for the trailer harness
• COOLING EXTERNAL TRANSMISSION OIL COOLER AUXILIARY HEAVY-DUTY AIR-TO-OIL
• SEATS FRONT POWER RECLINING FULL-FEATURE BUCKETS includes adjustable head restraints floor console driver and passenger power lumbar driver and front passenger 10-way power adjustable dual inboard armrests heated driver and passenger cushion and back 2-position driver-side memory and storage pockets (STD)
• TIRES LT215/85R16E ALL-SEASON BLACKWALL - Includes 7 tires with (E63) Pickup bed Wideside box. -Includes 6 tires with (ZW9) Pickup bed delete.
• TIRE SPARE LT215/85R16E ALL-SEASON BLACKWALL located at rear underbody of vehicle
• TRAILERING EQUIPMENT HEAVY-DUTY includes trailering hitch platform 7-wire harness (harness includes wires for: park lamps backup lamps right turn left turn electric brake lead battery and ground) with independent fused trailering circuits mated to a 7-way sealed connector 7-way to 4-way trailer adapter instrument panel jumper wiring harness for electric trailer brake controller and 1-way sealed connector for center high-mounted stop/brake lamp. Also includes (K47) Air cleaner high capacity
• ENGINE BLOCK HEATER (Included with (LLY) Engine Duramax 6600 Turbo Diesel V8)
• SOUND SYSTEM ETR AM/FM STEREO WITH 6-DISC CD CHANGER includes seek-and-scan digital clock auto-tone control speed-compensated volume TheftLock Radio Data System (RDS) and Bose speaker system (includes 6-speakers Bose amplifier and Bose Subwoofer) (STD)
• TRANSMISSION ALLISON 1000 5-SPEED AUTOMATIC ELECTRONICALLY CONTROLLED WITH OVERDRIVE AND ELECTRONIC GRADE BRAKING includes tow/haul mode selector and (KNP) Cooling external transmission oil cooler -Includes transmission temperature gauge)
• ENGINE DURAMAX 6600 TURBO DIESEL V8 (with Manual Transmissions 300 HP [223.8 kW] @ 3000 rpm 520 lb.-ft. [702.0 N-m] @ 1600 rpm) (with Automatic Transmissions 310 HP [231.2 KW] @ 3000 rpm 590 lb.-ft. [796.5 N-m] @ 1600 rpm) (Includes (TQ3) Battery heavy-duty dual 770 cold-cranking amps (K47) Air cleaner high capacity and (K05) Engine block heater)
• REGULAR PRODUCTION ACCESSORY ASSIST STEPS CHROME PLATED TUBULAR STAINLESS STEEL.
• SLT PREFERRED EQUIPMENT GROUP includes standard equipment
• BATTERY HEAVY-DUTY DUAL 770 COLD CRANKING AMPS includes rundown protection and retained accessory power
• PICKUP BED WIDESIDE BOX (STD)
• DIFFERENTIAL LOCKING HEAVY-DUTY REAR
• GVWR 11 400 lbs (5171 kg) (STD) (Includes dual rear wheels)
• MIRRORS OUTSIDE REARVIEW POWER HEATED CAMPER-STYLE includes power extending arms and turn signal in glass
• HEAVY-DUTY POWER PACKAGE includes (LLY) Engine Duramax 6600 Turbo Diesel V8 (M74) Transmission Allison 1000 5-speed automatic and (G80) Differential locking heavy-duty rear
• SEAT TRIM LEATHER (STD)
• AIR CLEANER HIGH-CAPACITY (Included with (LLY) Engine Duramax 6600 Turbo Diesel V8 (Z82) Trailering equipment heavy-duty or (VYU) Snow Plow Prep Package)
• REAR AXLE 3.73 RATIO
• SPARE TIRE LOCK
• Four Wheel Drive
• Tow Hooks
• Dual Rear Wheels
• Tires - Front All-Season
• Tires - Rear All-Season
• Conventional Spare Tire
• Dual Rear Wheels
• Steel Wheels
• Power Steering
• ABS
• 4-Wheel Disc Brakes
• Automatic Headlights
• Daytime Running Lights
• Automatic Headlights
• Fog Lamps
• Heated Mirrors
• Power Mirror(s)
• Privacy Glass
• Intermittent Wipers
• Leather Seats
• Power Driver Seat
• Power Passenger Seat
• Bucket Seats
• Heated Front Seat(s)
• Driver Adjustable Lumbar
• Passenger Adjustable Lumbar
• Seat Memory
• Rear Bench Seat
• Power Driver Seat
• Power Passenger Seat
• Floor Mats
• Adjustable Steering Wheel
• Leather Steering Wheel
• Immobilizer
• Rear Defrost
• Cruise Control
• Power Door Locks
• Power Windows
• Security System
• Keyless Entry
• Power Door Locks
• Telematics
• Requires Subscription
• Climate Control
• Multi-Zone A/C
• A/C
• AM/FM Stereo
• CD Changer
• CD Player
• Premium Sound System
• Steering Wheel Audio Controls
• Rear Seat Audio Controls
• Power Outlet
• Power Outlet
• Auto-Dimming Rearview Mirror
• Passenger Vanity Mirror
• Front Reading Lamps
• Front Reading Lamps
• ABS
• 4-Wheel Disc Brakes
• Driver Air Bag
• Passenger Air Bag
• Daytime Running Lights
• Automatic Headlights

• Electrical
• Cold Cranking Amps @ 0° F (Primary): 770
• Cold Cranking Amps @ 0° F (Primary): 600
• Cold Cranking Amps @ 0° F (2nd): 770
• Maximum Alternator Capacity (amps): 105
• Cooling System
• Total Cooling System Capacity (qts): 23.84
• Total Cooling System Capacity (qts): 13.32
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 4800
• Gross Axle Wt Rating - Rear (lbs): 8550
• Curb Weight - Front (lbs): 3424
• Curb Weight - Rear (lbs): 2791
• Gross Vehicle Weight Rating Cap (lbs): 11,400
• Gross Combined Wt Rating (lbs): 22,000
• Gross Combined Wt Rating (lbs): 16000
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 12000
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 9300
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 1800
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 1395
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): 9300
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): 2325
• Suspension
• Suspension Type - Front: Torsion Bar
• Suspension Type - Rear: 3-Stage Springs
• Spring Capacity - Front (lbs): 4800
• Spring Capacity - Rear (lbs): 8600
• Axle Type - Rear: Full-Floating
• Axle Capacity - Front (lbs): 4800
• Axle Capacity - Rear (lbs): 9200
• Axle Ratio (:1) - Front: 3.73
• Axle Ratio (:1) - Rear: 4.10
• Shock Absorber Diameter - Front (mm): 35
• Shock Absorber Diameter - Rear (mm): 35
• Stabilizer Bar Diameter - Front (in): 1.25
• Brakes
• Brake Type: Pwr
• Brake ABS System: Four-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 12.8 x 1.5
• Rear Brake Rotor Diam x Thickness (in): 12.8 x 1.2
• Tires
• Front Tire Order Code: XEC
• Rear Tire Order Code: XEC
• Spare Tire Order Code: XEC
• Front Tire Size: LT215/85R16
• Rear Tire Size: LT215/85R16
• Spare Tire Size: LT215/85R16
• Front Tire Capacity (lbs): 2430
• Rear Tire Capacity (lbs): 2150
• Spare Tire Capacity (lbs): 2430
• Revolutions/Mile @ 45 mph - Front: - TBD -
• Revolutions/Mile @ 45 mph - Rear: - TBD -
• Revolutions/Mile @ 45 mph - Spare: - TBD -
• Wheels
• Front Wheel Size (in): 16 x 6.5
• Rear Wheel Size (in): 16 x 6.5
• Spare Wheel Size (in): 16 x 6.5
• Front Wheel Material: Steel
• Rear Wheel Material: Steel
• Spare Wheel Material: Steel
• Steering
• Steering Type: Pwr Recirculating Ball
• Steering Ratio (:1), On Center: 24.1
• Steering Ratio (:1), At Lock: - TBD -
• Turning Diameter - Curb to Curb (ft): 55.5
• Turning Diameter - Wall to Wall (ft): - TBD -
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 34
• Fuel Tank Location: LH
• Exterior Dimensions
• Wheelbase (in): 167.0
• Length, Overall w/o rear bumper (in): 256.1
• Width, Max w/o mirrors (in): 96.1
• Height, Overall (in): 76.2
• Overhang, Front (in): 37.0
• Overhang, Rear w/o bumper (in): 52.1
• Front Bumper to Back of Cab (in): 148.1
• Cab to Axle (in): 55.9
• Cab to End of Frame (in): - TBD -
• Ground to Top of Load Floor (in): 34.4
• Ground to Top of Frame (in): - TBD -
• Frame Width, Rear (in): - TBD -
• Ground Clearance, Front (in): 10.6
• Ground Clearance, Rear (in): 13.6
• Cargo Area Dimensions
• Cargo Box Length @ Floor (in): 97.6
• Cargo Box Width @ Top, Rear (in): 61.9
• Cargo Box Width @ Floor (in): 64.8
• Cargo Box Width @ Wheelhousings (in): 50.0
• Cargo Box (Area) Height (in): 19.5
• Tailgate Width (in): 61.9
• Cargo Volume (ft³): 55.6
• Ext'd Cab Cargo Volume (ft³): - TBD -
• Interior Dimensions
• Passenger Capacity: 6
• Front Head Room (in): 41.0
• Front Leg Room (in): 41.3
• Front Shoulder Room (in): 65.2
• Front Hip Room (in): 61.4
• Second Head Room (in): 39.0
• Second Leg Room (in): 38.6
• Second Shoulder Room (in): 65.1
• Second Hip Room (in): 62.9
• Summary
• Vehicle Name: GMC Sierra 3500
• Body Style: Crew Cab 8' Fleetside
• Body Code: E63
